Fasergekoppelter 2-Achsen AOD / 532 nm

Hersteller: AA OPTO ELECTRONIC Artikelnummer: DTSXY-Gx1-Fi-PM1-J1-A

Kategorie: 2-Achsen

15.530,00 €

exkl. 19% USt. , zzgl.

Lagermäßig nicht vorrätig

Beschreibung
Benachrichtigen, wenn verfügbar

This high-resolution deflector is equipped with an input polarization maintaining fiber in order to have a plug and play deflector (PnP AOD): no Bragg angle adjustment, no beam alignment.

They operate with Te02 shear mode and hence offer a large scan angle as well as high resolution. Associated to the appropriate RF driver, such AOD provides high precision and accuracy which is required for most applications such as optical tweezers, biomedical diagnostics and many others. They are available with both 1-axis and 2-axis configurations.

Wesentliche Spezifikationen
Parameter	Rating
Acoustic velocity	650 m/s
Operation wavelength	532 nm
Rise time	Typ. 4 µs
Input/ Output polarization	Linear (aligned to fiber slow axis)
Access time	Typ. 6 µs
Output scan angle	41 mrad x 41 mrad
Frequency bandwidth	50 MHz
Fiber type	Panda PM480
Diffraction efficiency	Typ. > 30 %
Output free space beam	Typ. 3 mm (1/e²)
Max. optical Input power	300 mW
Max. RF-power	1 W (per axis)
